6'.00'' Lathe Machine We have established ourselves as the leading manufacturer and exporter of highly gauged lathe machines. The 6'.00'' Lathe Machine is ready to be used for various industrial applications. For the production of items like bolts, candlestick holder, crankshafts, camshafts, and many more these machines are most ideal. With below given specifications 6'.00'' Lathe Machine is available. Specification
Capacity
|
Metric
|
Height of Center
|
250mm.
|
Admitt Between Center
|
450 / 725 / 900 mm.
|
Bed
|
Bed Type
|
2 V & 2 Flat
|
Bed Width
|
279 mm.
|
Main Spindle
|
Size of Theaded Spindle Nose
|
6.T.P.I. 75 mm.
|
Taper Bore in Spindle Sleeve
|
MT-4
|
Spindle Bore
|
52 mm.
|
Tail Stock
|
Ram Diameter
|
50 mm.
|
Ram Travel
|
150 mm.
|
Speeds
|
No. of Speeds
|
6
|
Range
|
40-550 RPM
|
Thread / No. Range
|
Lead Screw Diameter & Pitch
|
31.75 mm. X 4 TPI
|
Metric
|
19 / 0.50 to 8.0 mm.
|
Inch
|
23 / 4 to 40 TPI
|
Standard Accessories
- Chuck Back Plate
- Spindle Sleeve
- 2-Dead Center
- Change Gear Set
- Tool Post Spanner
- Switch Stand
- Motor Pulley
Extra Accessories
- Steady Rest.
- Follow Rest.
- Rear Tool Post
- Face Plate
- Norton Gear Box
- Flame Hardened Bedways
- Taper Turning Attachment
- Electrical Coolant Pump With Fittings
- Electric Motor
- True Chuck
- Dog Chuck
- Reversible Switch
- V-belt
- Machine Lamp
|
